Cable de Alimentación Estándar Europeo NYY-J / NYY-O CE
NYY-J / NYY-O
Aplicación y descripción
Los cables de alimentación NYY se dedican al suministro de energía de conductos de cables, centrales eléctricas, tableros industriales y de distribución y redes de usuarios. También se puede utilizar en paredes de ladrillo y hormigón (hormigón no compacto). El cable no se puede instalar en una posición de vibración o balanceo. Los cables NYY pueden instalarse al aire libre, tendidos bajo tierra, en el agua y en interiores, pero se deben evitar los daños mecánicos. El cable es resistente a los rayos UV y se puede utilizar en exteriores.
estándar
VDE-0276 Parte 603 y Parte 627, HD 603.1 y 627 S1, IEC 60502, VDE 0482-332-1-2,
DIN EN60332-1-2 / IEC 60332-1, directivas CE de baja tensión 73/23 / EEC y 93/68 / EEC, ROHS
Estructura de cable
-Conductor de cobre desnudo trenzado o sólido
-Seguir DIN VDE 0295 cl.1 / cl.2, BS 6360 cl.1 / cl.2, IEC 60228 cl.1 / cl.2
-Categoría DIV4 de aislamiento de PVC, siga HD 603.1
-La codificación de colores cumple con DIN VDE 0293-308, 0276-603 / HD 186
-3 + 1/2 color del núcleo del conductor
Tipo J: amarillo-verde (1/2), marrón, negro, gris
Clase O: azul (1/2), marrón, negro, gris
-Revestimiento exterior de PVC categoría DMV5, siga HD 603.1
Parámetros de cable
Calibre del cable |
Número de núcleos x área de la sección transversal del conductor # x mm² |
Diámetro exterior nominal mm |
Peso de cobre nominal kg / km |
Peso nominal del cable kg / km |
12 | 1x4re | 9.0 | 38.0 | 130.0 |
10 | 1x6re | 10.0 | 58.0 | 136.0 |
8 | 1x10re | 11.0 | 96.0 | 182.0 |
6 | 1x16re | 12.0 | 154.0 | 252.0 |
4 | 1x25rm | 13.0 | 240.0 | 365.0 |
2 | 1x35rm | 14.0 | 336.0 | 480.0 |
1 | 1x50rm | 16.0 | 480.0 | 620.0 |
2/0 | 1x70rm | 17.0 | 672.0 | 840.0 |
3/0 | 1x95rm | 19.0 | 912.0 | 1100.0 |
4/0 | 1x120rm | 21.0 | 1152.0 | 1320.0 |
300mcm | 1x150rm | 23.0 | 1440.0 | 1610.0 |
350mcm | 1x185rm | 25.0 | 1776.0 | 1.980.0 |
500mcm | 1x240rm | 28.0 | 2304.0 | 2550.0 |
750mcm | 1x300rm | 30.0 | 2880.0 | 3200.0 |
- | 1x400rm | 34.0 | 3840.0 | 4000.0 |
- | 1x500rm | 38.0 | 4800.0 | 5100.0 |
16 | 3x1.5re | 12.0 | 43.0 | 225.0 |
14 | 3x2.5re | 13.0 | 72.0 | 275.0 |
12 | 3x4re | 14.0 | 115.0 | 375.0 |
10 | 3x6re | 15.0 | 173.0 | 480.0 |
8 | 3x10re | 18.0 | 288.0 | 675.0 |
6 | 3x16re | 19.0 | 461.0 | 880.0 |
4 | 3x25rm | 24.0 | 720.0 | 1390.0 |
2 | 3x35sm | 25.0 | 1008.0 | 1600.0 |
1 | 3x50sm | 28.0 | 1440.0 | 2000.0 |
2/0 | 3x70sm | 31.0 | 2016.0 | 2700.0 |
3/0 | 3x95sm | 35.0 | 2736.0 | 3600.0 |
4/0 | 3x120sm | 39.0 | 3456.0 | 4400.0 |
300mcm | 3x150sm | 44.0 | 4320.0 | 4910.0 |
350mcm | 3x185sm | 49.0 | 5328.0 | 6520.0 |
500mcm | 3x240sm | 53.0 | 6912.0 | 8290.0 |
4 | 3x25rm/16re | 25.0 | 874.0 | 1575.0 |
2 | 3x35sm/16re | 26.0 | 1162.0 | 1700.0 |
1 | 3x50sm/25rm | 30.0 | 1680.0 | 2325.0 |
2/0 | 3x70sm/35sm | 35.0 | 2352.0 | 2900.0 |
3/0 | 3x95sm/50sm | 37.0 | 3216.0 | 3900.0 |
4/0 | 3x120sm/70sm | 42.0 | 4128.0 | 4900.0 |
300mcm | 3x150sm/70sm | 47.0 | 4992.0 | 5800.0 |
350mcm | 3x185sm/95sm | 51.0 | 6240.0 | 7400.0 |
500mcm | 3x240sm/120sm | 59.0 | 8064.0 | 9700.0 |
- | 3x300sm/150sm | 66.0 | 10080.0 | 12000.0 |
16 | 4x1.5re | 13.0 | 58.0 | 220.0 |
14 | 4x2.5re | 14.0 | 96.0 | 300.0 |
12 | 4x4re | 16.0 | 154.0 | 410.0 |
10 | 4x6re | 17.0 | 230.0 | 520.0 |
8 | 4x10re | 19.0 | 384.0 | 720.0 |
6 | 4x16re | 22.0 | 614.0 | 1050.0 |
4 | 4x25rm | 26.0 | 960.0 | 1650.0 |
2 | 4x35sm | 28.0 | 1344.0 | 1860.0 |
1 | 4x50sm | 31.0 | 1920.0 | 2500.0 |
2/0 | 4x70sm | 35.0 | 2688.0 | 3300.0 |
3/0 | 4x95sm | 38.0 | 3648.0 | 4500.0 |
4/0 | 4x120sm | 42.0 | 4608.0 | 5500.0 |
300mcm | 4x150sm | 47.0 | 5760.0 | 6880.0 |
350mcm | 4x185sm | 52.0 | 7104.0 | 8460.0 |
500mcm | 4x240sm | 59.0 | 9216.0 | 11000.0 |
16 | 5x1.5re | 13.0 | 72.0 | 280.0 |
14 | 5x2.5re | 15.0 | 120.0 | 360.0 |
12 | 5x4re | 16.0 | 192.0 | 490.0 |
10 | 5x6re | 18.0 | 288.0 | 650.0 |
8 | 5x10re | 20.0 | 480.0 | 870.0 |
6 | 5x16re | 23.0 | 768.0 | 1255.0 |
4 | 5x25rm | 30.0 | 1200.0 | 1980.0 |
2 | 5x35rm | 34.0 | 1680.0 | 2650.0 |
16 | 7x1.5re | 14.0 | 101.0 | 370.0 |
16 | 10x1.5re | 17.0 | 144.0 | 530.0 |
16 | 12x1.5re | 18.0 | 173.0 | 580.0 |
16 | 14x1.5re | 19.0 | 202.0 | 620.0 |
16 | 16x1.5re | 20.0 | 230.0 | 690.0 |
16 | 19x1.5re | 21.0 | 274.0 | 770.0 |
16 | 21x1.5re | 22.0 | 302.0 | 850.0 |
16 | 24x1.5re | 23.0 | 346.0 | 900.0 |
16 | 30x1.5re | 24.0 | 432.0 | 1030.0 |
16 | 40x1.5re | 28.0 | 576.0 | 1260.0 |
16 | 61x1.5re | 32.0 | 878.0 | 1760.0 |
14 | 7x2.5re | 16.0 | 168.0 | 460.0 |
14 | 10x2.5re | 19.0 | 240.0 | 650.0 |
14 | 12x2.5re | 20.0 | 288.0 | 730.0 |
14 | 14x2.5re | 21.0 | 336.0 | 820.0 |
14 | 16x2.5re | 22.0 | 384.0 | 930.0 |
14 | 19x2.5re | 23.0 | 456.0 | 1000.0 |
14 | 21x2.5re | 24.0 | 504.0 | 1050.0 |
14 | 24x2.5re | 26.0 | 576.0 | 1120.0 |
14 | 30x2.5re | 28.0 | 720.0 | 1300.0 |
14 | 40x2.5re | 30.0 | 960.0 | 1700.0 |
14 | 52x2.5re | 36.0 | 1248.0 | 2300.0 |
14 | 61x2.5re | 38.0 | 1464.0 | 2600.0 |
14 | 7x4re | 19.0 | 269.0 | 620.0 |
14 | 7x6re | 21.0 | 403.0 | 860.0 |
