ANEN-plug-in bus connector and socket
ANEN connector product characteristics
1. Product Series = CROWN CLIP Junior
2. PCB retention structure = No
3. PCB mounting angle = horizontal
4. Printed circuit board terminal type = through hole-solder
5. UL certification=UL1977
Shell characteristics
1. Mating direction recognition = None
2. Shell material = thermoplastic
3. Shell color = black
Configuration characteristics:
1. Customizable = No
Industry Standard
1. RoHS/ELV compliant = RoHS compliant, ELV compliant
2. Lead-free soldering process = wave soldering up to 260°C, wave soldering up to 240°C
3. RoHS/ELV compliance record = always RoHS compliant
4. Institution/Standard=UL
5. UL certification = recognition
surroundings:
Working temperature (°C[°F])=-20–+75[-4–+167]
Conditions of Use:
Connection terminal = bus bar, printed circuit board, printed circuit board/bus bar
Operation/Application:
1. Application = board to bus bar
2. Contact transmission (typical application) = power supply
Packing characteristics:
1. Packaging method = plastic tray packaging
2. Replace Tyco material number: 1982995-1, 1982530-1, C-2178410, C-1982530, 1551953-1,
1. Product Series = CROWN CLIP Junior
2. PCB retention structure = No
3. PCB mounting angle = horizontal
4. Printed circuit board terminal type = through hole-solder
5. UL certification=UL1977
brand introduction
Brand: ANEN
Brand logo description: innovation in safety and environmental protection capabilities
ANEN will continue to innovate around everyone's needs with an aggressive attitude, provide customers with competitive products and solutions for power connectors, and jointly face future opportunities and challenges.
Mechanical connection:
1. Panel accessories=None
Electrical characteristics
1. Contact rated current (A)=150
2. Hot pluggable = yes
3. Working voltage reference = DC
4. Working voltage (VDC)=48
size
1. PCB thickness (mm[in])=1.50–2.00[0.060–0.079]
2. The length of the tail of the printed circuit board (mm[in])=4.40[0.173]
3. Length (X axis) (mm[in])=31.40[1.2362]
4. Width (Z-axis) (mm[in])=12.00[0.472]
5. Section height (Y axis) (mm[in])=28.25[1.112]
Main characteristics
1. The thickness of the bottom plate material (μm[μin])=1.20[47.240]
Contact characteristics:
1. Matching blade thickness (mm[in])=3.00[0.118]
2. Terminal material = copper
3. Contact area plating = tin
4. Contact plating, mating part, thickness (μm[μin])=3
5. Contact point bottom plating = nickel
6. Contact design = multi-contact contact piece/CROWNBAND
