MOLEX Automotive Connector Power Distribution System
Molex automotive connectors refer to various automotive connectors widely used in automotive products. Compared with 2010, the number of connectors used in ordinary new cars has doubled in 2020. Electronic devices in the car have increased. In response to this form, MOLEX provides corresponding solutions to simplify the vehicle's power distribution system.
MOLEX Automotive Connector Application Classification
Car Equipment
Car audio / car computer / car GPS navigator / car display in this type of product application. Molex provides flexible circuit board sockets (FPC) based on its leading advantages in consumer electronics products, Common type and floating type board to board (BTB), Wire to board (WTB), Wire to wire (WTW), Memory Card Socket, Input and output interface (I/O), Camera Socket, Radio Frequency Connector (RF), Power Connector, Membrane Switch, PCB board assembly (PCBA), cable assembly (Cable Assembly) and other complete product services.
In-car interconnection network type
It is mainly used in the transmission of signals and images between the front and rear seats required by modern high-end cars. In addition to the above-mentioned products, it is mainly HSAutoLink™ products that comply with the USCAR standard.
Automobile special type
1. Power system
Car Equipment
Car audio / car computer / car GPS navigator / car display in this type of product application. Molex provides flexible circuit board sockets (FPC) based on its leading advantages in consumer electronics products, Common type and floating type board to board (BTB), Wire to board (WTB), Wire to wire (WTW), Memory Card Socket, Input and output interface (I/O), Camera Socket, Radio Frequency Connector (RF), Power Connector, Membrane Switch, PCB board assembly (PCBA), cable assembly (Cable Assembly) and other complete product services.
In-car interconnection network type
It is mainly used in the transmission of signals and images between the front and rear seats required by modern high-end cars. In addition to the above-mentioned products, it is mainly HSAutoLink™ products that comply with the USCAR standard.
Automobile special type
1. Power system
OBD II, MX150, MX64, MX120, SCC, CMC and other customized products are widely used in automotive power systems. Such as oil circuit, valve mechanism, emission control, engine cooling, engine control, ignition control and four-wheel drive.
2, the body system
NSCC, UCC, 250, 040, 040III, 630, 090+250 mixed type, 030+090 mixed type, 040+090 mixed type. Various types of wire to board (WTB) such as H3, HDX, MOX, MX150. Wire to Wire (WTW) connector, temperature sensor connector. Car light connectors, horns, wipers, anti-theft holder connectors and various customized products are widely used in power distribution, insurance, car doors, windows, mirrors, heating/air conditioning, security systems, etc.
3. Information Control System
090, Blade Header, VDL, MiniFit, audio mixing input and output connectors. 0.64 hybrid USCAR connector. H-DAC 64, NSCC, HDX, 040 III, 040, MOST, FAKAR and other custom connectors are widely used in dashboards, antennas, vehicle information interconnection, intelligent transportation systems, electronic non-stop toll collection systems, etc.
2, the body system
NSCC, UCC, 250, 040, 040III, 630, 090+250 mixed type, 030+090 mixed type, 040+090 mixed type. Various types of wire to board (WTB) such as H3, HDX, MOX, MX150. Wire to Wire (WTW) connector, temperature sensor connector. Car light connectors, horns, wipers, anti-theft holder connectors and various customized products are widely used in power distribution, insurance, car doors, windows, mirrors, heating/air conditioning, security systems, etc.
3. Information Control System
090, Blade Header, VDL, MiniFit, audio mixing input and output connectors. 0.64 hybrid USCAR connector. H-DAC 64, NSCC, HDX, 040 III, 040, MOST, FAKAR and other custom connectors are widely used in dashboards, antennas, vehicle information interconnection, intelligent transportation systems, electronic non-stop toll collection systems, etc.
Fourth, the security system
ABS connector, seat belt connector, airbag connector, MX64, anti-collision sensor connector, waterproof connector, ignition connector. MX150, NSCC and other custom connectors are widely used in ABS systems, seat belt systems, airbag systems, car collision avoidance, pedestrian protection systems, etc.
Features and advantages
· Fully protective plastic shell can protect the pins when plugging or unplugging.
· Polarized anti-misoperation slot can guide the guide rail when the connector is inserted to prevent the pin from being damaged.
· The latch window provides forced locking after plugging.
· Push-type fixing bolts provide greater holding force to the printed circuit board during soldering.
Electrical parameters
Insulation dielectric strength: 1500 volts
Insulation resistance: 1000 megohms, minimum
Mechanical parameters
Holding force of contact and plastic case: 17.79 Newtons (4 pounds)
Pluggable times: 25 times of tinning, 50 times of gold-plating
Physical parameter
Physical parameters physical parameters plastic case: Black high temperature resistant thermoplastic, flame retardant grade is UL 94V-0.
Terminal material: copper alloy
