The d-sub connector is a type of connector. The d-sub connector has a variety of models, options and accessories, and is a very economical interconnection solution. Including high and low frequency mixed, high current and high density d-sub connector, d-sub connector, including insulating body, harpoon plate lock, back cover and multiple conductive terminals; After assembling, the harpoon-shaped plate lock is confined in the limit mechanism, thereby effectively solving the problem of uneven foot height caused by the unreliable locking position of the harpoon-shaped plate and easy rotation of the existing d-sub connector.

Features

Typical applications of D-Sub interface are VGA (DA15 female), parallel port (DB25 female), COM serial port (DE9 male, RS232)
Different definitions of 25pin d-sub connector signal in different modes: Computer parallel port
The main features of sht10 are as follows: The measurement of relative humidity and temperature has dew point output. Features: Standard structure, beautiful appearance, easy installation, conforming to multiple standards.

Product Specifications

Specification: de-9pz.
Product category: Rectangular connector...
The main technical parameters:
Working temperature: -55～125℃. Rated voltage: 300v;

Wire harness for D-SUB connector

The d-sub connector is a type of connector. The d-sub connector has a variety of models, options and accessories, and is a very economical interconnection solution. Including high and low frequency mixed, high current and high density d-sub connector, d-sub connector, including insulating body, harpoon plate lock, back cover and multiple conductive terminals; After assembling, the harpoon-shaped plate lock is confined in the limit mechanism, thereby effectively solving the problem of uneven foot height caused by the unreliable locking position of the harpoon-shaped plate and easy rotation of the existing d-sub connector.

Precautions for welding

(1) It is recommended to wrap a layer of thermal insulation tape on the inner mold before wrapping the copper foil to prevent the core wire from being scalded when welding the copper foil or injecting the outer mold;
(2) The coated copper foil is not allowed to be slit or damaged;
(3) If the copper foil is found to be damaged, the damaged part can be covered with copper foil, and then the joint between the patched copper foil and the original copper foil should be completely welded with solder;
(4) After the copper foil is completely wrapped, it is not allowed to see the inner mold or the exposed core wire from any angle;
(5) Be careful not to scald the core wire during welding.
(6) It is not allowed to cause the solder to dissolve into the gap between the inner mold and the connector, and the solder penetrates into the thermal insulation tape of the inner mold.

D-SUB connector	Compact pin and interface slots Our complete D-Sub connector series ranges from right-angle and vertical PCB connectors to AMPLIMITE 0.050 series D-Sub connectors. Our D-Sub connector product portfolio is suitable for a variety of applications, with special accessories, and can provide any customer with an economical D-Sub solution suitable for any complex application. The AMPLIMITE D-Subminiature connector complies with MIL-DTL-24308 specifications. 109 series and 90 series and ULTRA-LITE series connectors provide a full range of contact density, and can reduce weight and achieve EMI shielding. Our product portfolio includes AS39029 contacts as well as coaxial contacts and power contacts. Right Angle PCB Vertical PCB Cable installation In addition to a complete set of standard military ultra-small D-type connectors to choose from, YAXUN also provides special application versions, such as connectors with hybrid power/coaxial cable cavity and size 20 signal contacts; Provides a one-time interface suitable for high-use straight-through connectors and special non-magnetic connectors with rubber gaskets on the rear for stress relief.
D-SUB connector terminal	SZ 22, SOCKET, NON-MAG D-Sub connector terminal: pin, brass, signal, size 20 The D-Sub pin snap-in connector terminals are made of brass and use No. 20 terminals to terminate wires and cables. The wire diameter range is 32-18 AWG for signal circuit applications. CONTACT PIN ASSY, SZ 8   D-Sub connector terminal: pin, brass, signal, size 22 The D-Sub pin snap-in connector terminals are made of brass and are terminated to wires and cables with No. 22 terminals. The wire diameter range is 28-22 AWG and is used for signal circuit applications. CONT, CRIMP PIN, 18AWG, 109, SZ 20 D-Sub connector terminal: socket, CuSn4, square pole, signal, size 20 The D-Sub socket connector terminals are made of phosphor bronze, and the No. 20 terminal is connected to the printed circuit board through a square post. The operating temperature range is -55-105°C and is used for signal circuit applications.
D-SUB accessories	D-SUB back cover Reinforced metal connector tail cover, suitable for No. 1 (9/15 position) D subminiature connector, practical structure, few individual parts, quick and easy installation and assembly. D-SUB quick lock pin with threaded pin Existing systems can be easily retrofitted with threaded insert quick-lock pins for D-Sub connector tail caps.   Wire clamp for 1-3STD/1-4 QL size housing Two-piece D-sub cable clamp for 1-3STD/1-4 QL size housing. Achieve high-efficiency stress relief because the cable outlet is equipped with ribs that prevent the cable from jamming.   Wire clamp for No. 4 5STD/5QL housing Two-piece D-sub cable clamp for No. 4 5STD/5QL housing. Achieve high-efficiency stress relief because the cable outlet is equipped with ribs that prevent the cable from jamming.
Micro and nano micro D connectors	M83513/01-CN, MCKS-N1-B-21PS 095-0604-2030=MCDR3-B-9SS M83513/01-AN, MCKS-N1-B-9PS M83513/02-AN, MCKS-N1-B-9SS
