HY2.0, PH2.0 electronic docking terminal line
Model: ZH1.5, HY2.0, ZH2.5, PH2.0 docking terminal line
The distinguishing method of the electronic docking terminal line is mainly reflected in the difference in printing:
3C standard: CCC A0438****227 IEC 08 (90) 300/500V **mm GB4035 5-1997 SHENGPAI
UL standard: E249743 AWM 1007 **AWG 80℃ 300V VW-1 CHENGXING AWM I I A **awg 80℃ 300V FT1
VDE standard: VDE H05V-K 300V/500V **mm NR.485***23 SHENGPAI
General electronic wire, its general nominal name is AWG (American Wire Gauge) as the unit. According to normal standards, internal conductors should be divided into bare copper and tinned copper. The wire diameter specifications of commonly used regular wires are shown in the following table:
UL10368 detailed specifications
The distinguishing method of the electronic docking terminal line is mainly reflected in the difference in printing:
3C standard: CCC A0438****227 IEC 08 (90) 300/500V **mm GB4035 5-1997 SHENGPAI
UL standard: E249743 AWM 1007 **AWG 80℃ 300V VW-1 CHENGXING AWM I I A **awg 80℃ 300V FT1
VDE standard: VDE H05V-K 300V/500V **mm NR.485***23 SHENGPAI
General electronic wire, its general nominal name is AWG (American Wire Gauge) as the unit. According to normal standards, internal conductors should be divided into bare copper and tinned copper. The wire diameter specifications of commonly used regular wires are shown in the following table:
UL10368 detailed specifications
| Model number |
Wire specifications
|
Wire core structure
(number of cores/mm) |
Diameter of wire core
(mm) |
Thickness
(mm) |
Finished outer diameter
(mm) |
| UL10368 |
32AWG
|
7*0.08
|
0.24
|
0.25
|
0.74
|
| UL10368 |
30AWG
|
7*0.10
|
0.31
|
0.25
|
0.81
|
| UL10368 |
28AWG
|
7*0.127
|
0.39
|
0.25
|
0.89
|
| UL10368 |
26AWG
|
7*0.16
|
0.49
|
0.25
|
0.99
|
| UL10368 |
25AWG
|
7*0.18
|
0.55
|
0.25
|
1.05
|
| UL10368 |
24AWG
|
11*0.16
|
0.61
|
0.25
|
1.11
|
| UL10368 |
23AWG
|
11*0.18
|
0.69
|
0.25
|
1.19
|
| UL10368 |
22AWG
|
17*0.16
|
0.76
|
0.25
|
1.26
|
| UL10368 |
21AWG
|
21*0.16
|
0.85
|
0.25
|
1.35
|
| UL10368 |
20AWG
|
21*0.18
|
0.95
|
0.25
|
1.45
|
| UL10368 |
19AWG
|
21*0.20
|
1.06
|
0.25
|
1.56
|
| UL10368 |
18AWG
|
41*0.16
|
1.18
|
0.25m
|
1.68
|
| UL10368 |
17AWG
|
33*0.20
|
1.33
|
0.25
|
1.83
|
| UL10368 |
16AWG
|
26*0.254
|
1.5
|
0.25
|
2
|
| UL10368 |
15AWG
|
52*0.20
|
1.67
|
0.25
|
2.17
|
| UL10368 |
14AWG
|
41*0.254
|
1.88
|
0.25
|
2.38
|
| UL10368 |
13AWG
|
52*0.254
|
2.12
|
0.25
|
2.62
|
| UL10368 |
12AWG
|
65*0.254
|
2.37
|
0.25
|
2.87
|
| UL10368 |
11AWG
|
81*0.254
|
2.64
|
0.25
|
3.14
|
| UL10368 |
10AWG
|
105*0.254
|
3.41
|
0.25
|
3.91m
|
