FEP / PFA / PTFE Teflon cable supplier

China's teflon FEP / PFA / PTFE cable supplier provides high temperature UL, CSA certification cable, cross section have 14~32 awg. 4mm silver plated copper structure conductor electrical cables.
Fluoroplastic cables are used to specifically refer to wires and cables with fluoroplastics as the jacket. Fluoroplastic cables have excellent weather resistance, heat resistance, low friction coefficient, stable chemical properties, and good electrical insulation properties. Therefore, fluoroplastic cables have important applications in industries with harsh environments such as petroleum, metallurgy, chemical industry, electric power, and aerospace. In the production of wires and cables, commonly used fluoroplastics include polytetrafluoroethylene, polyperfluoroethylene propylene, polyvinylidene fluoride, tetrafluoroethylene and ethylene copolymers. It is used to manufacture all kinds of heat-resistant, high-temperature resistant insulated wires, well cables, geological exploration cables, heating cables, and lead wires for F-class and H-class motors. Radiation resistant wires, electromagnetic wires, radio frequency coaxial cables, A-type cables for flame-retardant cables used in coal mines, etc.

Color: tan, red, white, yellow, green, brown, black, blue, pink, etc.
Size: 24AWG, 22AWG, 20AWG, 18AWG, 16AWG, 14AWG, 12AWG, 10AWG, 8AWG, 6AWG, 4AWG, 2AWG, 1AWG, 1 / 0AWG, 2 / 0AWG, 3 / 0AWG, 4 / 0AWG
Packing: 305M/roll

250°C 600V UL5181 PTFE high temperature wire with glass fiber braid
describe    Feature Structure Product Image
Name: High temperature wire
Model: AWM5181
Size: 24~4 / 0awg
Rated voltage: 600V
Rated temperature: 250℃
Conductor: nickel-plated wire, pure nickel wire
Insulation: PTFE wrapping
Sheath: glass fiber braid, high temperature coating
 250°C UL5181 with glass fiber braided high temperature wire

250°C 600V UL5196 PTFE high temperature cable with glass fiber
describe    Feature Structure Product Image
Name: High temperature cable
Model: AWM5196
Size: 24~4 / 0awg
Rated voltage: 600V
Rated temperature: 250℃
Conductor: nickel-plated wire, pure nickel wire
Insulation: PTFE wrapping, glass fiber wrapping
Sheath: glass fiber braided, high temperature coating
 UL5196 PTFE high temperature cable with glass fiber

250°C 300V UL5180 PTFE braided glass fiber high temperature cable
describe    Feature Structure Product Image
Name: High temperature cable
Model: AWM5180
Size: 24~2AWG
Rated voltage: 300V
Rated temperature: 250℃
Conductor: nickel-plated wire, pure nickel wire
Insulation: PTFE wrapping, glass fiber wrapping
Sheath: woven glass fiber, high temperature coating
 UL5180 PTFE tape braided glass fiber high temperature cable

200℃ 300V UL20711 FEP cable
describe    Feature Structure Product Image
Name: FEP wire
Model: AWM 20711
Size: 2*18~7*14AWG
Rated voltage: 300V
Rated temperature: 200℃
Conductor: tin-plated copper, nickel-plated copper
Insulation: Extruded FEP
Filler: FEP insulated glass fiber
Package: Polyester yarn
Blocking: optional
Jacket: FEP
 200℃ 300V UL20711 FEP cable

200℃ 600V UL20710 FEP cable
describe    Feature Structure Product Image
Name: FEP wire
Model: AWM 20710
Size: 2*18~7*14AWG
Rated voltage: 600V
Rated temperature: 200℃
Conductor: tin-plated copper, nickel-plated copper
Insulation: Extruded FEP
Filler: FEP insulated glass fiber
Package: Polyester yarn
Blocking: optional
Jacket: FEP
 200℃ 600V UL20710 FEP cable

200℃ 600V UL20369 FEP cable
describe    Feature Structure Product Image
Name: FEP cable
Model: AWM 20369
Size: 2*18~7*14AWG
Rated voltage: 600V
Rated temperature: 200℃
Conductor: tin-plated copper, nickel-plated copper
Insulation: Extruded FEP
Filler: FEP insulated glass fiber
Package: Polyester yarn
Blocking: optional
Jacket: FEP
 200℃ 600V UL20369 FEP cable

200℃ 600V UL2750 FEP cable
describe    Feature Structure Product Image
Name: FEP wire
Model: AWM 2750
Size: 2*18~7*14AWG
Rated voltage: 600V
Rated temperature: 200℃
Conductor: tin-plated copper, nickel-plated copper
Insulation: Extruded FEP
Filler: FEP insulated glass fiber
Package: Polyester yarn
Blocking: optional
Jacket: FEP
 200℃ 600V UL2750 FEP cable

250℃ 1000V UL10371 PFA cable
describe    Feature Structure Product Image
Name: PFA line
Model: AWM 10371
Size: 30~4 / 0awg
Rated voltage: 1000V
Rated temperature: 250℃
Conductor: tin-plated, nickel-plated copper
Insulation: Extruded PFA
Standard: UL758, UL1581
 250℃ 1000V UL10371 PFA cable

Cable de 250C 600V UL1727 PFA
describe    Feature Structure Product Image
Nombre: cable PFA
Modelo: AWM 1727
Tamaño: 32 ~ 4 / 0AWG
Voltaje nominal: 600 V
Temperatura nominal: 250 ℃
Conductor: tin-plated, nickel-plated copper
Insulation: Extruded PFA
Standard: UL758, UL1581
 Cable de 250C 600V UL1727 PFA

250℃ 300V UL1726 PFA cable
describe    Feature Structure Product Image
Name: PFA cable
Model: AWM 1726
Size: 32~4 / 0AWG
Rated voltage: 300V
Rated temperature: 250℃
Conductor: tin-plated, nickel-plated copper
Insulation: Extruded PFA
Standard: UL758, UL1581
 250℃ 300V UL1726 PFA cable

250C 10KV/15KV/20KV/25KV UL1911 PFA cable
describe    Feature Structure Product Image
Name: PFA wire
Model: AWM 1911
Size: 24~10AWG
Rated voltage: 5KV, 10KV, 15KV, 20KV, 25KVDC
Rated temperature: 250℃
Conductor: tin-plated copper, nickel-plated copper
Insulation: Extruded PFA
Meet the standards: UL758, UL1581
 250C 10KV/15KV/20KV/25KV UL1911 PFA cable
