The meaning of power cord specifications and models
Power cord specifications and selection: RV, AVR, RVB, RVS, RVV, ARVV, RVVB, RV-105, AF-205AFS-250AFP-250.
RV: Copper core vinyl chloride insulated connection cable (wire).
AVR: Tinned copper core polyethylene insulated flat connection flexible cable (wire).
RVB: Copper core PVC flat connecting wire.
RVS: Copper core PVC stranded connecting wire.
RVV: Copper core PVC insulated PVC sheathed round connection flexible cable.
ARVV: Tinned copper core PVC insulated PVC sheathed flat connecting flexible cable.
RVVB: Copper core PVC insulated and sheathed flat connection flexible cable.
RV-105: Copper core is heat-resistant 105.
C PVC insulated PVC insulated connection flexible cable.
AF-205AFS-250AFP-250: Silver-plated polychloroethylene fluoride plastic insulation, high temperature resistance-60. C~250. CConnect the flexible cable.

Technical standards for power cords
The selection of the power cord is carried out according to some principles. Relevant requirements such as quality and appearance are also implemented in accordance with the power cord certification regulations. The principles for manufacturing power cords are as follows:
(1) According to the requirements for the selection of power transmission conductor cross-sections in the "Technical Regulations for Power System Design" SDJ161-85 issued by the Ministry, select the conductor cross-section of the DC transmission power line;
(2) "110~500kV Overhead Transmission Line Design Technical Regulations" DL/T5092-1999;
(3) "Technical Guidelines for High Voltage Direct Current Overhead Transmission Lines" DL436-2005.
